Control for up to 260000+parameters
connection with DPU
16384 Parameters
2 internal motorized foldable monitor multi- touch screens
2 internal motorized foldable letterbox multi- touch screens
1 internal multi-touch command screens
5 large touch encoders with RGB backlight
21 small encoders with RGB backlight
1 Grand encoders with RGB backlight
1 Dimmer encoders with RGB backlight
15motorized faders with RGB backlight scales
2 motorized A/B faders(long)with RGB backlight scales
60 executor keys with RGB backlight
20 Xkeys with RGB backlight
67+6 keys with RGB backlight
Built-in 2 drawers
Built-in uninterruptible power supply(UPS)
Built-in SIM&WIFI
Built-in infrareds,microphones
Built-in double cameras(front +rear)
Built-in security fingerprint scanner with RGB backlight
Control for up to 260000+parameters
connection with DPU
16384 Parameters
2 internal motorized foldable monitor multi- touch screens
2 internal motorized foldable letterbox multi- touch screens
1 internal multi-touch command screens
5 large touch encoders with RGB backlight
21 small encoders with RGB backlight
1 Grand encoders with RGB backlight
1 Dimmer encoders with RGB backlight
15motorized faders with RGB backlight scales
2 motorized A/B faders(long)with RGB backlight scales
60 executor keys with RGB backlight
20 Xkeys with RGB backlight
67+6 keys with RGB backlight
Built-in 2 drawers
Built-in uninterruptible power supply(UPS)
Built-in SIM&WIFI
Built-in infrareds,microphones
Built-in double cameras(front +rear)
Built-in security fingerprint scanner with RGB backlight
- 8 x DMX 512 In/Out(5pin XLR female/3pin XLR female)
3 x ether CON/RJ45(10/100/1000M)
3 + 2× USB(type A)
2 x DP for external screens
1 x MIDI In(5pin DIN female)
1 x MIDI Out(5pin DIN female)
1 × LTC In(3pin XLR female)
1 x Audio In(3pin XLR female)
1 x Audio Out(3.5mm)
2 × S/PDIF In and Out
2 x LED desk light(4pin XLR female)
Power Supply: 100-240V,50/60Hz
Maximum Power: 130W
Power Factor: ≥0.95
Product Dimension: 848x684x178mm(fold), 848x528x452mm(unfold)
Package: 1 pc / flight case
Net Weight: 42.6 kg
IP Rate: IP 20
Work Temperature: -10℃~40℃
- 8 x DMX 512 In/Out(5pin XLR female/3pin XLR female)
3 x ether CON/RJ45(10/100/1000M)
3 + 2× USB(type A)
2 x DP for external screens
1 x MIDI In(5pin DIN female)
1 x MIDI Out(5pin DIN female)
1 × LTC In(3pin XLR female)
1 x Audio In(3pin XLR female)
1 x Audio Out(3.5mm)
2 × S/PDIF In and Out
2 x LED desk light(4pin XLR female)
Power Supply: 100-240V,50/60Hz
Maximum Power: 130W
Power Factor: ≥0.95
Product Dimension: 848x684x178mm(fold), 848x528x452mm(unfold)
Package: 1 pc / flight case
Net Weight: 42.6 kg
IP Rate: IP 20
Work Temperature: -10℃~40℃
- Dust Cover
LED Lights
Stylus
User Manual
- Dust Cover
LED Lights
Stylus
User Manual
